Access Control

U1：Lower U-bracket of Electric Bolt, for Using with DS-K4T100.
U2：Upper and lower U-bracket of Electric Bolt, for Using with DS-K4T100.

U1：Lower U-bracket of Electric Bolt, for Using with DS-K4T100.
U2：Upper and lower U-bracket of Electric Bolt, for Using with DS-K4T100.

Turnstile Remote Controller, Communication frequency：433MHz

Secure module. Communicates with the access control terminal via RS-485 to execute the commands from the terminal including open door, close door, normally open and normally closed
Input interface: Door Magnetic×1, Tamper-proof×1, Alarm input x2;
Output interface: Door Switch Relay×1, Alarm Relay×1.
DC 12V.
Dimensions：48 mm × 115 mm × 26 mm (1.9" × 4.5" × 1.0")

M1 Contactless Smart card, Frequency: 13.56vMHz.
Designed with the PVC and AB glue
Dimension(L×W×H): 26 mm × 50 mm × 4 mm (1.02" × 1.97" × 0.16")
suggest to be used with the below reader series：DS-K1107M/MK、DS-K1108M/MK、DS-K1104M/MK

Supports enrolling face picture, fingerprint, 13.56 MHz M1 card, DESfire card,Felica card and 125KHz EM card.
3.97-inch LCD touch screen,2 Mega pixel wide-angle lens;
Supports TCP/IP, USB communication,DC 12V/2A
Dimensions：121.6 mm × 137.9 mm × 125 mm (4.8" × 5.4" × 4.9")

Supports enrolling face picture, 13.56 MHz M1 card, DESfire card,Felica card and 125KHz EM card.
3.97-inch LCD touch screen,2 Mega pixel wide-angle lens;
Supports TCP/IP, USB communication,DC 12V/2A
Dimensions：121.6 mm × 137.9 mm × 125 mm (4.8" × 5.4" × 4.9")

Plug-and-play USB with no-driver technology, USB 2.0;
Fingerprint enrollment for DS-K1T201, DS-K1201, DS-K1T804, DS-K1A802 and DS-K1T501.

Plug-and-play USB with no-driver technology;
Supports various card types (M1 card and EM card). Card Issuer for Project Market
