IP video intercom kit for villa or house, only one call button.
DS-KV6113-WPE1(C) x1;
DS-KH6320-WTE1 x1;
PSU x2;
Power adapter included in the package（European Standard）

7“ Screen LCD Indoor Station, Video Intercom Communication,Support picture storage,time OSD , brightness, contrast,volume adjusting, and ringtone selecting
Supports Three Indoor Stations Cascading in Intercom System;
Remote Unlocking, Monitoring Door Station and External Analog Camera.

7“ Screen LCD Indoor Station, Video Intercom Communication,
Supports Three Indoor Stations Cascading in Intercom System;
Remote Unlocking, Monitoring Door Station and External Analog Camera.

Pinhole Camera with 1920*1080 resolution, Video Intercom Communication;
Supports Two Door Stations Cascading in Intercom System;
Unlocking Controlling, Self-adaptive IR Supplement.
Anti-oxidant zinc alloy; IP65.

Pinhole Camera with 1920*1080 resolution, Video Intercom Communication;
Supports Two Door Stations Cascading in Intercom System;
Unlocking Controlling, Self-adaptive IR Supplement.

Two-wire version: 7“ Touch-Screen Indoor Station,
7-inch Colorful TFT LCD, display resolution: 1024 * 600;
10/100Mbps Ethernet, Wi-Fi 802.11b/g/n;
Two -wire interface.
TF card, max 32G; 32MB Flash;
8-ch alarm input, 2xalarm output, 1x485

Two-wire version:Main unit , stainless steel, needs mouting bracket.
CMOS 2MP HD Colorful Camera, Fish eye, 1 Call Button, 1-ch Indoor station access, 2 relays for door lock control
IR Supplement , 10M/100M Self-adaptive Ethernet, module connection with RS-485 , 4-ch alarm input
IP65, Two -wire interface,98mmx99.8mmx43.9mm
Mouting accessories and other modules are same as IP version of modular door station.

Two-wire version:Main unit , stainless steel, needs mouting bracket.
CMOS 2MP HD Colorful Camera, Fish eye, no Call Button, 1-ch Indoor station access, 2 relays for door lock control
IR Supplement , 10M/100M Self-adaptive Ethernet, module connection with RS-485 , 4-ch alarm input
IP65, Two -wire interface,98mmx99.8mmx43.9mm
Mouting accessories and other modules are same as IP version of modular door station.

Two-wire version: CMOS 2MP HD Colorful Camera, Fish eye (Horizontal: 146°, Vertical:82° ), 1 Call Button, 2-ch Indoor station access
IR Supplement , 10M/100M Self-adaptive Ethernet, module connection with RS-485 , 4-ch alarm input
IP65, Two -wire interface,98mmx99.8mmx43.9mm
Mouting accessories and other modules are same as IP version of modular door station.

1 RJ-45 Interface, 6 Two-Wire Interface to connect DS-KAD706Y & DS-KAD706Y-S, Reset button
Din rail mounting, 24VDC
Include power adapter
The model with Y is not compatible with previous version，they can not be used together.

1 RJ-45 Interface, 6 Two-Wire Interface to connect DS-KAD706Y & DS-KAD706Y-S, Reset button
Din rail mounting, 24VDC
Without power adapter
The model with Y is not compatible with previous version，they can not be used together.

1 RJ-45 Interface, 6 Two-Wire Interface to connect DS-KD8003Y-IME2 or DS-KH6320Y-WTE2, 1 in interface to connect DS-KAD706Y & DS-KAD706Y-S, 1 out interface to connect DS-KAD706Y & DS-KAD706Y-S,, Reset button
Din rail mounting, 24VDC
Include power adapter
The model with Y is not compatible with previous version，they can not be used together.

1 RJ-45 Interface, 6 Two-Wire Interface to connect DS-KD8003Y-IME2 or DS-KH6320Y-WTE2, 1 in interface to connect DS-KAD706Y & DS-KAD706Y-S, 1 out interface to connect DS-KAD706Y & DS-KAD706Y-S,, Reset button
Din rail mounting, 24VDC
Without power adapter
The model with Y is not compatible with previous version，they can not be used together.

1 RJ-45 Interface, 4 Two-Wire Interface to connect device, 1 in interface to connect DS-KAD706Y & DS-KAD706Y-S, 1 out interface to connect DS-KAD706Y & DS-KAD706Y-S, Reset button
Din rail mounting, 24VDC
The model with Y is not compatible with previous version，they can not be used together.

Keypad module for KD9633 series door station, including 15 buttons,
1 USB type-C, only connect to KD9633
Backlight compensation behind the keypad, IP65 & IK07
Gang box with extention module is included!

Keypad & Fingerprint module for KD9633 series door station, 5000 Fingerprints capacity
1 USB type-C, only connect to KD9633
Backlight compensation behind the keypad, IP65 & IK07
Gang box with extention module is included!

Keypad module for KD9403 series door station, including 15 buttons,
1 USB type-A, only connect to KD9403
Backlight compensation behind the keypad, IP65
Gang box with extention module is included!

Keypad & Fingerprint module for KD9403 series door station, 5000 Fingerprints capacity
1 USB type-A, only connect to KD9403
Backlight compensation behind the keypad, IP65
Gang box with extention module is included!

Face Recognition Android Door Station, 10.1-inch IPS touch screen, Display resolution: 1280 * 800,
Android 7.1, 2x2 Mega pixel wide-angle lens, Built-in Mifare card reading module, Wifi & Bluetooth reserverd;
Max.10000 faces capacity, Max.20000 users;
Supports TCP/IP,DC 12V, 4-ch alarm input
IP65,IK07, 1 relays for door lock control, 1 RS-485 for DS-K2M060 to control the second door lock.
Gang box without extention module is included!

Face Recognition Android Door Station, 10.1-inch IPS touch screen, Display resolution: 1280 * 800,
Android 7.1, 2x2 Mega pixel wide-angle lens, Built-in Mifare card reading module;
Max.10000 faces capacity, Max.20000 users;
Supports TCP/IP,DC 12V, 4-ch alarm input
IP65,IK07, 1 relays for door lock control, 1 RS-485 for DS-K2M060 to control the second door lock.
Gang box without extention module is included!
